ONE-PACK POLYURETHANE MAINTENANCE PRIMER No 700

Specification Data

Type

One-pack，moist curing type of primer that based on polyisocyanate resin with rust inhibitors such as zinc powder.

Uses

Used for steel structures，harbor facilities，bridges，pipelines

Characteristics

˙one-pack packing can result to cost-effectiveness and time saving.

˙Moist curing type of coating can be applied under highly humid environment.

˙Excellent permeability to surface due to low viscosity of coating . It can tightly seal and adhere the steel structure surface and its rusty façade.

˙Suitable to rusty steel surface that can only be cleaned by hand or by high pressure water but is unable to clear by blasting.

˙Excellent chemical and water resistance and weatherability . Qualified by the standard of CNS 10757 K6801 3000hrs salt spray test.

˙Quick drying to shorten application period.

Color

Finish

Brown and Gray

Flat

Service Temperature

100℃(212℉)

VOC values

Solids Content

360 g/L.

By Weight Above 85%

Zinc Content in Dry

Film

By Weight Above 70%

Theoretical Coverage

38.0 m²/Gal (409 ft²/Gal)10.0 m²/L (107.6 ft²/L)4.6 m²/Kg (49.5 ft²/Kg)( DFT :2.4 mils)

Dry Film Thickness

Dry：2.4milsWet：4mils

Preceding Coats

Polyurethane、Epoxy and Fluorine Topcoating.

Repair

itself

General

Remove dirt, dust, oil and all other contaminants that could interfere with adhesion of the coating.

Surfaces must be clean and dry. Moisture, grease, sludge, dust, corrosive salt must be thoroughly cleaned from substrate.

Steel

Areas of

Breakdown and

Damage

Surface preparation standards can use SSPC-SP10 or Sa2 1/2 (ISO 8501-1:2007).

It should be prepared to the specified standard (Sa2 1/2 (ISO 8501-1:2007) or SSPC-SP6, Abrasive Blasting or SSPC-SP11, Power Tool Cleaning) and patch primed prior to the application of No.700.

Mixing

Thinning

Use No.736 thinner to thin up 3~5%.(Excluded use for cleaning)

Spray Application

Airless

Spray

Brush

Roller

Avoid applying the paint in rainy weather or the relative humidity exceed 85%, particularly, a wet surface must be thoroughly dried. All equipment must be cleaned immediately after use. To increase or decrease the usage of thinner depending on the temperature of the coated surface, the temperature decreased may have to add more amount of thinner

Pump ratio 30:1 or greater

Tip size : 0.017’’~ 0.021’’

Output PSI : 2500~3800

Application by brush is applicable. For special condition please consult with product manufacturer.

Application by roller is applicable. For special condition please consult with product manufacturer.

Condition

Coating

Surface

Environment

Humidity

Minimum

10℃ (50℉)

10℃ (50℉)

10℃ (50℉)

30%

Maximum

45℃ (113℉)

60℃ (140℉)

45℃ (113℉)

85%

Surface Temp. &

50% Relative Humidity

Set to touch

Dry hard

Overcoating

Intervals

(Min)

Overcoating

Intervals

(Max)

10℃ (59℉)

90 minutes

12 hours

25℃ (77℉)

30 minutes

3 hours

3 hrs

30 days

35℃ (95℉)

20 minutes

2 hours

Cleanup

Safety

Ventilation

Use No.736 to clean. In case of spillage, absorb and dispose of in accordance with local applicable regulations.

Please read and follow all caution statements on this product data sheet and MSDS for this product.

Proper ventilation and protective measures must be provided during application and drying to keep solvent vapor concentrations within safe limits and to protect against toxic or oxygen deficient hazards.

Shelf Life

1 years under normal storage conditions

Shipping Weight

Storage

Temperature & Humidity

Flash Point

Storage

1 Gallon – 8.6kg

5-35℃ (41-95℉)

0-90% Relative Humidity

13℃ (55℉)

Avoid sunlight exposure or temperature exceeds 35℃.
