EP-116 EPOXY MULTI-PURPOSE PRIMER

EPOXY MULTI-PURPOSE PRIMER

PRODUCT NUMBER EP-116
TYPE The two-pack, universal anticorrosion primer based on epoxy resin, hardener and special pigments.
USES Used for the new building system or the maintenance system, including ship’s all areas such as ballast tank, underwater hull, topside, deck, cargo tank, oil tank, superstructure, interior etc. Also used for anticorrosion engineering of steel structure such as chemical factories, bridges, power plants, inlet and outlet pipes, drains and sewers etc.
CHARACTERISTICS

1. Simplified procedure, convenient application, unique long terms anticorrosive performance.

2. Excellent anticorrosion and adhesion, widely used for shop primer, steel plate (sand-blasted or mechanical surface preparation), aluminum, stainless steel, galvanized steel etc.

3. Can be coated with epoxy or polyurethane paint well.

4. Excellent resistance to mechanical damage.

5. Excellent resistance to sea water and corrosion, suitable for steel and non-ferrous metal.

6. Easy application, very fast drying, available for all year round.

FINISH

Flat

COLOR

Yellowish Green, Grey, Red Oxide

FLASH POINT

26℃

MASS DENSITY

Above 1.3 Kg/L

DRYING TIME

Set-to-touch 1 1/2 hrs. Dry hard 4 hrs. (25℃)

OPTIMUM FILM THICKNESS

Wet 125~333 microns Dry 75~200 microns

VOLUME SOLIDS

60%

THEORETICAL COVERAGE 30.3 ㎡/Gal 8 ㎡/L @ 75 microns

OVERCOATING INTERVALS

Overcoating table for two-pack type epoxy paint:

Substrate Temperature
5℃ 10℃ 20℃ 30℃ 40 ℃
Minimum 13 hours 6 hours 2.5 hours 1.5 hours 1 hour
Maximum
(Not directly exposed to sun)
6 months 6 months 6 months 4 months 3 months
Maximum
(Directly exposed to sun)
3 months 3 months 3 months 2 months 2 months

MIXING RATIO

Base : Hardener = 80 : 20 (by volume) = 86 : 14(by weight.)
POT LIFE 6 hrs. (25℃)
THINNER No.1005 Epoxy Thinner(SP-12)
THINNING RATE Brush / Roller : 0~5﹪ Airless spray : 0~10﹪ (Can not be used more than usage amount.)
SUBSEQUENT COATS Epoxy, Polyurethane, Acrylic, Chlorinated Rubber, Vinyl or Fire-retardant Paint
STORAGE SHELF LIFE Minimum 1 year under normal storage conditions.
APPLICATION METHOD Airless Spray, Brush, Roller
NOTE

1. Mix base and hardener according to the mixing ratio and stir thoroughly.

2. Adhered moisture, salt, grease, sludge, dust and rust on substrate must be removed thoroughly.

3. Surface of steel must be pretreated by sand-blasting to reach ISO-Sa 2 1/2 or with high pressure water-jet to reach VIS WJ 2/3.

4. Surface of shop primer must be pretreated by sand-sweeping to reach ISO SS or St3.

5. Avoid applying the paint in raining weather or the relative humidity exceeded 85% RH or substrate temperature below the dew point 3℃.

6. When used inside tanks, sufficient ventilation must be provided.
