EP-80HS EPOXY HIGH SOLID TANK LINING COATING

EPOXY HIGH SOLID TANK LINING COATING


PRODUCT NUMBER

EP-80HS

TYPE

A two-pack, high-solid lining coating based on epoxy phenolic resin with special pigments.

USES

Used for the tank lining such as cement, bridges, storage tanks, pipelines, petrochemical plants, steel structures etc.

CHARACTERISTICS

1. Two-pack type epoxy phenolic resin coating special designed for tank lining.

2. Excellent water resistance, withstand hot water up to 60℃.

3. Excellent resistance to oils and chemicals.

4. Suitable for use to protect the tank lining of cement and steel structure.

COLOR

Light gray, white

FLASH POINT

Above 28℃

MASS DENSITY

Above 1.4 Kg/L (mixture)

DRYING TIME

Set-to-touch 1.5 hrs. Dry hard 8hrs. Fully cured 7 days (25℃)

OPTIMUM FILM THICKNESS

Wet 167 microns Dry 100 microns

VOLUME SOLIDS

Above 60%

THEORETICAL COVERAGE

22.3 ㎡/Gal 5.9 ㎡/L 4.2 ㎡/Kg

OVERCOATING INTERVALS

Min. 4 hrs. (25℃)

MIXING RATIO

Base : Hardener = 87 : 13 (by wt.)

POT LIFE

4 hrs. (mixture, 25℃)

STORAGE SHELF LIFE

Minimum 2 years under normal storage conditions.

APPLICATION METHOD

Airless spray

FOR AIRLESS SPRAY

Tip Size 0.017” ~ 0.023”

Air Pressure 5 ~ 6 Kg/cm2

Pump Ratio 45 : 1 or greater

NOTE

1. Mix base and hardener according to the mixing ratio and stir thoroughly.

2. Adhered moisture, grease, dust and rust on substrate must be cleaned thoroughly.

3. Avoid applying the paint in rainy or humid above 85% R.H., particularly a wet surface must be thoroughly dried.

4. All equipment must be cleaned immediately after use.

5. The paint must be stored in ventilation and shade place, so do not place the paint in outdoor to exposure the sun, to avoid effect the quality of paint.

6. The usage amount of thinner depends on surface temperature of substrate to decide add or reduce. When temperature dropped, the usage amount of thinner was possible need to be increased.
