POLYURETHANE COATING
UP-450
Specification Data
Type A two-pack, high-solids colored coating based on acrylic polyol resin with non-yellowing polyisocyanate hardener.
Uses Used for wooden, metal, FRP products and steel structures such as ships, vehicles, bridges, oil refineries, power stations, pulp factories, chemical plants etc.
Characteristics High gloss and
excellent appearance.
Excellent weather resistance with gloss and color retention.
Excellent resistance to chemicals.
Excellent adhesion, hardness, flexibility and abrasion resistance.
|
Color |
A broad range of colors is upon customer request. |
|
Finish |
Gloss |
|
VOC values Volume Solids |
336 g/L , use No.736 thinner to thin up 5% (378 g/L) or 15% (445 g/L). Above 57% |
Theoretical Coverage 36 m2/Gal 9.5 m2/L 6.8 m2/Kg (DFT :2.4 mils)
Dry Film Thickness 1.6~3.2 mils per coat.
Dry film thickness in excess of 3.2 mils (80 microns) per coat is not recommended
Service Temperature Continuous
: 200
Non-Continuous :250
Preceding Coats
EP-999GF Epoxy High Solids Glass Flake Coating / No.1002 Epoxy Primer / No.1006 Epoxy Zinc
Rich Primer / No.1007 Epoxy Red Lead Primer / No.1009 Epoxy Red Oxide Primer / No.1050 Epoxy
M.I.O. Primer / No.1061 High Solids Epoxy Coating / No.700 One Pack Polyurethane Maintenance Primer
Performance Data
|
Test Method |
System |
Results |
|
ISO 4628-6-07 ISO 4624-02 Cyclic Corrosive Test |
Blasted Steel 1 ct. IZ-01 (75 microns) 1 ct. EP-999GF(150microns) 1 ct. UP-450 (60 microns) |
Chalking rating : 0.5 Original adhesive strength : 5.2 MPa Percentage of adhesive strength retention after cyclic corrosive test : 62.9%(3.27 MPa) |
|
ASTM F963 Soluble Heavy Metals Test |
1 ct. UP-450 |
|
|
CNS 15200-5-3 Flexibility |
1 ct. UP-450 |
No cracking and peeling on film |
|
CNS 15200-7-6 Impact resistance |
1 ct. UP-450 |
No cracking and peeling on film |
|
CNS 15200-5-6 Adhesiveness between layers |
1 ct. EP116 1 ct. UP-04 PU intermediate 1 ct. UP-450 |
No abnormality |
|
CNS 15200-6-1 Alkali resistance |
1 ct. EP116 1 ct. UP-04 PU intermediate 1 ct. UP-450 |
No abnormality |
|
CNS 15200-6-1 Acid resistance |
1 ct. EP116 1 ct. UP-04 PU intermediate 1 ct. UP-450 |
No abnormality |
n.d.(Sb As Cd Cr Pb Hg Se)
|
CNS 15200-7-4 Humidity and cool-heat cycling resistance |
1 ct. EP116 1 ct. UP-04 PU intermediate 1 ct. UP-450 |
Withstand humidity and cool-heat cycling |
|
CNS 15200-7-6 Accelerated weather resistance |
1 ct. EP116 1 ct. UP-04 PU intermediate 1 ct. UP-450 |
Withstand accelerated weather resistance test of 500hrs. Appearance :
No blistering cracking and peeling on film. Color difference: Not larger than reference sample. Chalking grade: 0 Gloss retaining ratio(%): 87 |
Test reports and additional data available upon written request.
Certification
Norsok
M-501-04 : Report number KV-12-08801XA-1 ( SGS Taiwan Ltd. )
CNS15665 K2247(2013) : Report number 140826373-1 (Taiwan Paint Industry
Association)
Application Instruction
Surface preparation
General Remove dirt, dust, oil and all other contaminants that could interfere with adhesion of the coating. Surfaces must be clean and dry. Moisture, grease, sludge, dust, corrosive salt must be thoroughly cleaned from substrate.
Primed Surfaces UP-450 should always be applied over a recommended anti-corrosive coating scheme. The primer surface should be dry and free from all contamination and UP-450 must be applied within the overcoating intervals specified (consult the relevant product data sheet).
Areas of It should be prepared to the specified standard (Sa2 1/2 (ISO 8501-1:2007) or SSPC-SP6, Abrasive Breakdown and Blasting or SSPC-SP11, Power Tool Cleaning) and patch primed prior to the application of UP-450. Damage
Mixing & Thinning
|
Mixing Thinning Mixing Ratio Pot life |
Mix base and hardener according to the mixing ratio and stir thoroughly. Use PU Thinner (No.736) to thin up 5~15%. Base : Hardener = 88 : 12 ( by weight ) 3
hours at 25 |
|
|
|
Equipment |
|
|
|
Spray Application
Airless Spray
Brush
Roller |
Avoid applying the paint in rainy or humid weather (the moisture above 85% RH), otherwise the adhesion will be affected by moisture of substrate and the paint film will be loss its gloss. All equipment must be cleaned immediately after use. When overcoating interval is exceeded, paint surface must be roughened to insure adhesion. Hardener cover must be tightly closed to avoid reaction with moisture in air to form bubbles and gelation. Pump ratio 30:1 or greater Tip size : 0.015’’~ 0.019’’ Output PSI : 2100~2500 Application by brush is applicable. For special condition please consult with product manufacturer. Application by brush is applicable. For special condition please consult with product manufacturer. |
( mixture, 77
)
Environment conditions
|
Condition |
Coating |
Surface |
Environment |
Humidity |
|
|
Normal |
|
) |
|
|
30~55% |
|
Minimum |
|
|
|
0% |
|
|
Maximum |
|
|
|
85% |
20~30 (68 ~86
20~30 (68 ~86 )
20~30 (68 ~86 )
5 (41 )
5 (41 )
5 (41 )
35 (95 )
42 (108 )
42 (108 )
Industry
standards are for substrate temperatures to be 3 (5 ) above
the dew point . the product simply requires the substrate temperature to be
above the dew point.
Caution : This Product is moisture sensitive in the liquid stage and until cured. Protect from high humidity ,dew and direct moisture contact until cures. Application and/or curing in humidities above maximum, or exposure to moisture from rain or dew may result in a loss of gloss and/or microbubbling of the product.
Curing Schedule
|
Surface Temp. & 50% Relative Humidity |
Dry to Handle |
Dry to Recoat & Topcoat |
|
|
18 hours |
18 hours |
|
|
10 hours |
10 hours |
|
|
4 hours |
4 hours |
|
|
1.5 hours |
1.5 hours |
Cleanup & Safety
Cleanup
Safety Ventilation | Use PU Thinner (No.736) to clean. In case of spillage, absorb and dispose of in accordance with local applicable regulations. Please read and follow all caution statements on this product data sheet and MSDS for this product. Proper ventilation and protective measures must be provided during application and drying to keep solvent vapor concentrations within safe limits and to protect against toxic or oxygen deficient hazards. |
Package, Handling & Storage
Shelf Life
Shipping Weight | Part A :Minimum 2 years under normal storage conditions Part B :Minimum 1 years under normal storage conditions Part A : 1 Gallon – 4.94kg 5 Gallon – 24.1kg Part B : 1 Gallon – 0.74kg 5 Gallon – 3.3kg |
Storage
Temperature &
Humidity
Flash Point
Storage Store in dry, shaded conditions away from sources of heat and ignition.
|
|
|
|
 |
|
|
|
