1058HS HIGH SOLIDS EPOXY POTABLE WATER TANK LINING

1058HS HIGH SOLIDS EPOXY POTABLE WATER TANK LINING, CERTIFICATED ACCORDING TO JWWA K135


TYPE

A two-pack , high-solids tank lining paint based on special epoxy resin and hardener with water resistant pigment.

USES

Used for potable water tanks, fresh water tanks, farm tanks, steel pipes and cement pipes, and also suitable for ship cargo hold, crude oil tanks, ballast tanks and fresh water tanks etc.

CHARACTERISTICS

  1. High solids and high build (125µ film can be obtained by one coat spray).
  2. Tough, hard and high abrasion resistance.
  3. Excellent resistance to water, oils and mild chemicals.
  4. Meet JWWA K135.

FINISH

Semi-gloss

COLOR

Grey, brown

MASS DENSITY

Above 1.4 Kg/L(mixture)

VISCOSITY

110-140 KU (mixture, 25°C )

DRYING TIME

Set-to-touch 2hrs.Dry hard 6 hrs. Fully Dry 7days (25°C )

OVERCOATING INTERVALS

Min. 8 hrs.Max. 5 days (25°C ) or 3 days (30°C )

OPTIMUM FILM

Wet320 micronsDry 250 microns

THICKNESS THEORETICAL

11.8 m'/Gal3.1 m2/L2.2 m2/Kg@250µ

COVERAGE MIXING RATIO

Base : hardener= 83 : 17 (by wt.)

NON-VOLATILE CONTENT

Above 82%

HEAT RESISTANCE

(mixture) Continuous 93°C

THINNER

No.1005 Epoxy Thinner (SP-12)

THINNING RATE

0-10% (by wt. cleaning tools excluded)

STORAGE SHELF LIFE

Minimum 1 year under normal storage conditions.

APPLICATION METHOD

Airless Spray, Brush, Roller

SURFACE PREPRATION

Steel: sand blasting to SIS Sa 2 1/2 and above

Concrete: sand sweeping or with suitable roughness

NOTES

  1. Mix base and hardener according to the mixing ratio and stir thoroughly.
  2. Avoid applying the paint in rainy weather or humidity above 85% RH, particularly a wet surface must be thoroughly dried.
  3. When used inside tanks, sufficient ventilation must be provided.
  4. When applied in farm tanks, the conditions of application must be obeyed, and the self test is necessary for farm tanks before use.
